A210C10BM
A210C10BM Spin-On Cartridge
| OD (D1) (MM) | ID (D2) (MM) | LENGTH 1 (H1) (MM) | LENGTH 2 (H2) (MM) | THREAD SIZE | MEDIA/MICRON RATING | COLLAPSE PRESSURE (BAR) | WORKING PRESSURE (BAR) | BURST PRESSURE (BAR) | BYPASS FITTED | BYPASS SETTING (BAR) | FLOW DIRECTION | SEALS |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 96 | 0 | 148 | 0 | G 3/4 | C10 | 4 | 12 | 20 | YES | 1.7 | OUT-IN | NBR |
FA-2 TANK TOP RETURN LINE SPIN-ON FILTERS
Technical Information
Tank top return line spin-on filter assemblies.
Max flow Rate: 150 l/min (40gpm)
Max working pressure: As per NFPA T 3.10.17: 12 Bar (175 psi)
Test pressure: As per NFPA T 3.10.17: 15 Bar (217.5 psi)
Burst pressure: As per NFPA T 3.10.17: 20 Bar (290 psi)
Connection Ports: BSP
Indicator: visual and electrical
Working temperature: -25C + 100C
Materials:
Head: aluminium
Housing: carbon steel
Seal Buna-N
Fluids compatibility: ISO 2943: Filter assembly compatible with mineral oils and same synthetic or vegetable oils. With other fluid applications please contact filtrec S.p.A.
Filter Element:
Filter media: Microglass fiber 3,6,10,25,um Cellulose 10,25 um Wire mesh 60, 125um
Collapse pressure: As per ISO 2941: 4 Bar (58 psi)
By-pass setting: Return line: 1,7 Bar (24.6 psi)
THE GIVEN FLOW RATE VALUES REFER TO APPLICATIONS WITH MINERAL OIL HAVING VISCOSITIY OF 30 CST AT WORKING TEMPERATURE. FOR APPLICATIONS WITH DIFFERENT FLUID OR WORKING CONDITIONS, A CORRECTIVE FACTOR MUST BE APPLIED BY REFERING TO THE TECHNICAL INFORMATION.
Manufacturers code: A210C10BM
| MANUFACTURER | STOCK CODE |
|---|---|
| BALDWIN | BT8935 |
| CROSLAND | 7507 |
| DOMANGE | FDB31P10 |
| DONALDSON | CAR60.1 |
| DONALDSON | P171625 |
| DONALDSON | P565242 |
| FAI FILTRI | 03743021 |
| FAI FILTRI | CTT5003P10A |
| FBN | FHR1M10 |
| FILPRO | SOET510 |
| FILTER MART | 250336 |
| FILTER MART | 286468 |
| FLEETGUARD | HF7901 |
| FLUID POWER EXPRESS | LH070021 |
| LHA | TTE1510 |
| LUBER FINER | LFH8535 |
| MAIN FILTER | MF0058085 |
| MP FILTRI | CT050P10AB |
| MP FILTRI | CTT50P10A |
| NEW HOLLAND | 4574055 |
| OMT | CSM05ANR |
| RENAULT | X250615709 |
| SOFIMA HYDRAULICS | CA151ECD1M |
| SOFIMA HYDRAULICS | CCA151ECD1M |
| STAUFF | SFCT3510E |
| TERRI | T50335 |
| UFI | 8003600 |
| UFI | ERC11NCC |
| UNI-CARDAN | CR05AN |
| WIX | 92003EN |
| WIX | A13A10CBM |
| WOODGATE | WGUC2408 |
