A121G25

A121G25 Spin-On Cartridge

Spin On Filter Canisters

Technical Information

In line low-pressure spin-on filter assemblies, suction and return lines.

• Max flow rate: 300 l/min (79 gpm)
• Max working pressure: As per NFPA T 3.10.17: 12 Bar (175 psi)
• Test pressure: As per NFPA T 3.10.17: 15 Bar (217.5 psi)
• Burst pressure: As per NFPA T 3.10.17: 20 Bar (290 psi)
• Connection Ports: BSP
• By-pass setting: suction line 0,25 Bar (3.6 psi) return line 1,7 Bar (24.6 psi)
• Indicator: Visual and electrical
• Working temperature: -25C + 120C
• Materials:
• Head: aluminium
• Housing: carbon steel
• Seal: Buna-N
• Fluids compatibility: ISO 2943: Filter assembly compatible with mineral oils and some synthetic or vegetable oils. With other fluid applications please contact Filtrec S.p.A

Filter Element

• Filter media: Microglass fiber 3,6,10,25 um
• Cellulose: 10,25 um
• Wire mesh: 60, 125 um
• Collapse pressure: as per ISO 2941: 4 Bar (58 psi)

The given flow rate values refer to applications with mineral oil having a viscosity of 30 cst at the working temperature. For applications that use different fluids or working temperatures/conditions, a corrective factor must be applied by refering to the technical information. You can find our Technical PDF in the next tab.

Manufacturers code: A121G25
