A111C25
A111C25 Spin-On Cartridge
| OD (D1) (MM) | ID (D2) (MM) | LENGTH 1 (H1) (MM) | LENGTH 2 (H2) (MM) | THREAD SIZE | MEDIA/MICRON RATING | COLLAPSE PRESSURE (BAR) | WORKING PRESSURE (BAR) | BURST PRESSURE (BAR) | BYPASS FITTED | BYPASS SETTING (BAR) | FLOW DIRECTION | SEALS |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 96 | 0 | 213 | 0 | G 3/4 | C25 | 5 | 12 | 20 | NO | 0 | OUT-IN | NBR |
FA-1 HYDRAULIC RETURN LINE SPIN-ON FILTERS
Technical Information
In line low-pressure spin-on filter assemblies, suction and return lines.
Max flow rate: 300 l/min (79 gpm)
Max working pressure: As per NFPA T 3.10.17: 12 Bar (175 psi)
Test pressure: As per NFPA T 3.10.17: 15 Bar (217.5 psi)
Burst pressure: As per NFPA T 3.10.17: 20 Bar (290 psi)
Connection Ports: BSP
By-pass setting: suction line 0,25 Bar (3.6 psi) return line 1,7 Bar (24.6 psi)
Indicator: Visual and electrical
Working temperature: -25C + 120C
Materials:
Head: aluminium
Housing: carbon steel
Seal: Buna-N
Fluids compatibility: ISO 2943: Filter assembly compatible with mineral oils and some synthetic or vegetable oils. With other fluid applications please contact Filtrec S.p.A
Filter Element
Filter media: Microglass fiber 3,6,10,25 um
Cellulose: 10,25 um
Wire mesh: 60, 125 um
Collapse pressure: as per ISO 2941: 4 Bar (58 psi)
THE GIVEN FLOW RATE VALUES REFER TO APPLICATIONS WITH MINERAL OIL HAVING VISCOSITY OF 30 CST AT WORKING TEMPERATURE. FOR APPLICATIONS WITH DIFFERENT FLUID OR WORKING CONDITIONS, A CORRECTIVE FACTOR MUST BE APPLIED BY REFERING TO THE TECHNICAL INFORMATION.
Manufacturers code: A111C25
| MANUFACTURER | STOCK CODE |
|---|---|
| BALDWIN | BT8474 |
| BUSSE | HA071 |
| DIAMOND | FDI152025 |
| DONALDSON | 182080300 |
| DONALDSON | CA80.3 |
| DONALDSON | P171611 |
| EPPENSTEINER | 8.7SL60P25P |
| EPPENSTEINER | 80.6021P20S000P |
| FAI FILTRI | 03742452 |
| FAI FILTRI | CS7000P25A |
| FBN | FHL220N1 |
| FBN | FHL2M25 |
| FILPRO | SOE625 |
| FILTER MART | 545675 |
| FLEETGUARD | HF6538 |
| GROOT | GHCS7025 |
| IKRON | HEK4520180ASSP025 |
| IKRON | HHC01806 |
| LES HALL | LH058014 |
| LES HALL | LHE918269 |
| LHA | SPE2625 |
| MAIN FILTER | MF0058014 |
| MASSEY FERGUSON | 3657889M1 |
| MASSEY FERGUSON | 3668164M91 |
| MASSEY FERGUSON | 4204121M1 |
| MP FILTRI | CS070P25A |
| MP FILTRI | CS70P25A |
| NATIONAL FILTERS | SPFC110925PB |
| OMT | CS06BN |
| REXROTH | 80.6021P20S000M |
| REXROTH | 806021P20S000M |
| ROSROCA | S2Z31000000720 |
| SANDVIK | 912019900 |
| SEPARATION TECHNOLOGIES | ST5521 |
| SOFIMA HYDRAULICS | C152ECV |
| SOFIMA HYDRAULICS | CA152CV1 |
| SOFIMA HYDRAULICS | CA152ECV1 |
| SOFIMA HYDRAULICS | CCA152ECV1 |
| SOFIMA HYDRAULICS | S8006RH |
| STAUFF | SFC3625E |
| STEP FILTERS | HID44305 |
| UFI | 8000600 |
| UFI | ESE12NCD |
| UNI-CARDAN | CF06BN |
| WIX | A03A25C |
| WOODGATE | WGH9170 |
